Three phase AC motor technology

Driving, lifting, and steering are all controlled by three-phase AC motors

Powerful acceleration

Maintenance free motors without carbon brushes have a longer lifespan, lower maintenance costs, energy recharge during deceleration, and longer operating time

New hydraulic design

The brand new hydraulic design enhances the efficiency of the hydraulic system

High power lifting motor

New type of backlash free gear technology for low-noise gear pumps, high working efficiency, and long service life

More optimized intelligent design

CAN bus technology

Slope parking with automatic control

Driving speed control

Lifting speed control

Electronic control self-protection

Foot switch interlocked with driving

Advanced EPS electronic power steering

EPS electronic power steering provides a lightweight, flexible, efficient, and silent operation for the entire vehicle

Automatic centering function

Automatic speed and acceleration limit for steering

Five independent braking systems

Release the accelerator lever to activate the driving brake

Release the foot pedal switch to activate the emergency driving brake

Button triggered parking brake

Automatic start parking brake

Emergency power-off switch

Active safety system (2-2.5 tons)

Hydraulic handle triggered parking brake for the load wheel and drive wheel

Operation display

180 degree corner position display

Battery level and fault code display

Select driving mode

Lifting lock indication

Wide field of view door frame

Integral lateral shifter

When lifting to a high position, the remaining load is large

Lifting limit buffer

Maximum buffering for forward and backward movement of the gantry

Fork tilt (2-2.5 tons)

Comfortable cockpit

The driver's body is fully protected by the vehicle body

The cab is equipped with lumbar, head, and elbow support

Roof protection frame

Rear protection of the roof rack column for drivers and improvement of work visibility

The top fence board provides drivers with a wider field of view
